Laminated Tempered Baluster Glass Railing Prefabricated Frameless Type

Customer Reviews
DBM have make the amazing stuff ! I like the staircase and terrace railing very much. They are professional manufacturer, they design and custom based on European standards. Well done !

—— Julian Slade

They offer us the outside handrail and stairs to our apartment. We just installed,we missed some handrail during transportation, but the quality is good.

—— Mahamad Raikar

I'm Online Chat Now

Laminated Tempered Baluster Glass Railing Prefabricated Frameless Type

Laminated Tempered Baluster Glass Railing Prefabricated Frameless Type
Laminated Tempered Baluster Glass Railing Prefabricated Frameless Type Laminated Tempered Baluster Glass Railing Prefabricated Frameless Type Laminated Tempered Baluster Glass Railing Prefabricated Frameless Type

Large Image :  Laminated Tempered Baluster Glass Railing Prefabricated Frameless Type

Product Details:
Place of Origin: China
Brand Name: DBM
Certification: CE/ SGCC/ AS/NZ2208 /COC /PVOC /SASO
Model Number: DB-B3209
Payment & Shipping Terms:
Minimum Order Quantity: 15 meters
Price: Negotiation
Packaging Details: plywood package
Delivery Time: 35
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram

Laminated Tempered Baluster Glass Railing Prefabricated Frameless Type

Description
Material: Stainless Steel/aluminum/Carbon Steel Finished: Brushed/Mirror/Anodizing/Powder Coated
Size: Dia50.8/42.4/38mm, 50*50/40*40/38*38mm Delivery Time: 35 Days
Package: Plywood Glass: Tempered Glass/Laminated Glass
Mounted Way: Floor/Side Mounted Color: Silver/Customized
High Light:

deck railing glass balusters

,

glass baluster panels

Laminated Tempered Glass fancy Balcony Railing Terrace Baluster Glass Railing





Balustrade glass railing is used stainless steel baluster or post with tempered glass or laminated glass.

For stainless steel, normally we will use stainless steel 304 for interior and stainless steel 316 for exterior. It‘s good for rust protection.

If you have need the railings, please send the layout or sketch for the railings you need.

Then we can recommend you some design and make solution based on your job site.



Products Details:

Dimension Length Based on your job site
Height 900-1200mm or customized
Component & Size(mm) Handrail

Round Size: Dia50.8 / 42.4 / 38mm

Square Size: 50*50 / 40*40 / 38*38mm

Customized

Post

Round Size: Dia50.8 / 42.4 / 38mm

Square Size: 50*50 / 40*40 / 38*38mm

Customized

Height: Based on your job site

Glass

Single tempered glass: 8/10/12/15mm

Laminated tempered glass:

5+0.76+5mm / 6+0.76+6mm / 5+1.14+5mm / 6+1.14+6mm
8+1.14+8mm / 8+1.52+8mm / 10+1.52+10mm and others

Materials Handrail S.S304 / S.S316 / Carbon steel / Carbon steel
Post S.S304 / S.S316 / Carbon steel / Carbon steel
Glass Clear / Frosted / Stained / Hurricane Glass
Surface finished Brushed / Mirror / Powder coated
Installation DIY, No need weld and easy installation by yourself
Glass no need drill hole for this type railing
Installation manual and instruction drawing are available



Mounted Way for Baluster:

1. Floor / Top Mounted

2. Side / Wall Mounted



How to Choose material for your own house or project?

Stainless steel 304 Normally use for indoor railings, no raining and far away from oceans.
Stainless steel 316 Use for outdoor totally, if the weather is bad and alway get rain or snow, S.S316 is the best solution for rust protection.



Purchase Step:

1.

Dimension and design: please advise the length and height of railing and choose design;
2. Solution: offer solution and quotation based on the dimension provided and the design choosed from our website;
3. Negotiation: details, price, project schedule, delivery term, delivery time and payment etc.;
4. Shop drawing: we will offer shop drawing for customer to confirm;
5. Place order and production: according customers confirmed drawings with detail dimensions;
6. Delivery: according customers request.



Our advantage:

1. All the railing / balustrade height can be customized.

2. If you want different design, just send the pictures to us to see if we can do it;

3. We have done a lot of project before so we well know different countries have different building code;

4. We have attended 2019 International Builder Show in Las Vegas;

5. We have our own factory and we control good quality for the stairs and railings;

6. Response rate 92.6%;



Delivery time:
35 days after deposit and drawing confirmation



FAQ:
Q: If the top rail can not 100% match the job site, can i cut the top rail at job site?

A: Normally most of our top rail can fit for your job site, but in case of above situation, of course you can cut the top rail in your job site with band saw. It will not damage the surface finished.



Q: What information we should offer to quote?
A:If you have layout or house plan drawing please send us,if not please let me know the dimension of the railing you need.



Q: Have you made some project in our local? Do you know our building code and local standard?
A: We have finished house project in exceed 40 country so we well know the building code & standard.



Q: If we buy building materials from you,is it hard to install by ourslef?
A: All of our poducts easy to install and no need weld, we 100% sure you can install it without any problem.



Q: Do you have any installation guide/drawing for us?
A: We will send you detail installation manual and drawing,if you still not understand we can show you the installation video.



Q: If I don't want to see the screw on the base of the prost, do you have cladding for hiding the screw?
A: Yes. Please let us know if you want caldding.



Laminated Tempered Baluster Glass Railing Prefabricated Frameless Type 0

Laminated Tempered Baluster Glass Railing Prefabricated Frameless Type 1

Laminated Tempered Baluster Glass Railing Prefabricated Frameless Type 2



If any inquiry contact us freely. Thanks for your time!
